| Locator | Hist Soc - HS-CC02613 | Type | Drawing | Doc Number | 10672 | |
|---|---|---|---|---|---|---|
| Description | N&W Ry, Proposed Extension of Passing Siding at Graham Furnace, Va., MP N367+00 | |||||
| Notes | Scale 1"=200' | |||||
| Date | 07/08/1920 | Revision Date | ||||
| Author | N&W RR - Office of Chief Engr | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
||
Size: 34in x 13in (87cm x 33cm) |
| Cities Indexes | |
|---|---|
| City | State |
| Graham | VA |
| Structures Indexes | |
|---|---|
| Category | Type |
| Track | Siding |
| Track | Wye |
| Track | Passing |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W Rwy | Norfolk & Western Railway |
| Division Indexes | |||
|---|---|---|---|
| Road Name | Division | District/Branch | Mile Post |
| N&W Rwy | Pocahontas | Clinch Valley District | 367 |
| Related Documents | |||
|---|---|---|---|
| Type | Number | Locator | Description |
| Related | 10672-B | Hist Soc - HS-G10200 | Record of Construction of Extension of Passing Siding at Graham, VA |
| Related | 10672A | Hist Soc - HS-CC10898 | N&W Ry Co., Proposed Extension of Passing Siding at Graham Furnace, VA, M.P. 367+1069.7 |
