| Locator | Hist Soc - HS-K00282 | Type | Drawing | Doc Number | 7920 | |
|---|---|---|---|---|---|---|
| Description | N&W Ry, Norfolk Division, Proposed Layout of Tracks also Alterations to Coal Wharf at Dwight, Va. | |||||
| Notes | Scale 1"=100' | |||||
| Date | 11/15/1907 | Revision Date | ||||
| Author | N&W Rwy - Office Chief Engr | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
||
Size: 51in x 13in (130cm x 33cm) |
| Cities Indexes | |
|---|---|
| City | State |
| Dwight | VA |
| Structures Indexes | |
|---|---|
| Category | Type |
| Engine Service | Coaling |
| Track | Siding |
| Wharf | Coal |
| Track | Passing |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W Rwy | Norfolk & Western Railway |
| Division Indexes | |||
|---|---|---|---|
| Road Name | Division | District/Branch | Mile Post |
| N&W Rwy | Norfolk | 39 | |
