| Locator | NW Mech Dwg - NW-E42809 | Type | Drawing | Doc Number | E42809 | |
|---|---|---|---|---|---|---|
| Description | Arrangement of Crosshead and Pin with Timken Roller Bearings, Loco. Class J (Eng. No's. 600 to 604 only) | |||||
| Date | 12/06/1948 | Revision Date | 04/14/1954 | |||
| Author | N&W Railway | Accession | ||||
|
||
Size: 38in x 31in (96cm x 79cm) |
| Rolling Stock Indexes | |||||
|---|---|---|---|---|---|
| Category | Type | Road Name | Class | Builder | Other |
| Locomotive | Steam | N&W Rwy | J | Roanoke Shops | 4-8-4 |
