| Locator | Digital Scan - DS03257 | Type | Drawing | Doc Number | 5330 | |
|---|---|---|---|---|---|---|
| Description | N&W R'y, Radford Divsion, Map of Portion of New River Division, MP 302+4355 and MP 308+2961' | |||||
| Notes | Scale 1"=1000', Radford to Belspring across "Schooler Hill". Shows wye at New River and low grade line at Belspring. Also Belspring station on old line | |||||
| Date | 11/08/1901 | Revision Date | ||||
| Author | N&W Rwy - Off. Engr Maint Way | Accession | 2018.003 : John S. Garner | |||
|
||
Size: 30in x 15in (77cm x 38cm) |
| Cities Indexes | |
|---|---|
| City | State |
| Radford | VA |
| Belspring | VA |
| New River | VA |
| Schooler | VA |
| Structures Indexes | |
|---|---|
| Category | Type |
| Track | Wye |
| Station | |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W RR | Norfolk & Western Railroad |
| N&W Rwy | Norfolk & Western Railway |
| Division Indexes | |||
|---|---|---|---|
| Road Name | Division | District/Branch | Mile Post |
| N&W Rwy | Radford | ||
| N&W RR | New River | ||
