| Locator | NW Mech Dwg - NW-C25185 | Type | Drawing | Doc Number | C25185 | |
|---|---|---|---|---|---|---|
| Description | Composite Drawing of 50 Ton Bettendorf Type Side Frames (Not Checked) | |||||
| Notes | Shows many variations of side frames on one drawing, comparing to A.R.A. standard side frame. | |||||
| Date | 04/15/1925 | Revision Date | ||||
| Author | N&W Rwy - Motive Power | Accession | 2008.001 : Roanoke Chapter - NRHS | |||
|
||
Size: 24in x 16in (61cm x 41cm) |
| Rolling Stock Indexes | |||||
|---|---|---|---|---|---|
| Category | Type | Road Name | Class | Builder | Other |
| Component | Truck | N&W Rwy | |||
