| Locator | Hist Soc - HS-C00053 | Type | Drawing | Doc Number | N-7500 | |
|---|---|---|---|---|---|---|
| Description | Typical designs for coal trestle. | |||||
| Notes | four A/B sized sheets on one C size page: N-7500 Sheet 51 (Coal Trestle Type Y-1950), N-7500 sheet 52 (Concrete piers and wood stringer, type Y-1950), N-7500 sheets 52-A and 52-B (I-Beam stringers and concrete piers) | |||||
| Date | Revision Date | |||||
| Author | N&W Railway | Accession | ||||
|
|
|
Size: 19in x 15in (49cm x 39cm) |
| Parent | N-7500 | Hollinger - Hol-01011.20 | Index to Sheets to N-7500 4 pages. Individual sheets/sets linked. Not all sheets were in folder. Missing sheets: 34 (have A,B,C), 84A (have 84,B,C), 96, 112, 114, 115, 117, 135 (have 135A), 141,141A,141B (have 141C, D1, D2), 144 (have A,B). |
| Structure | Coal - Trestle |
| Company | N&W Rwy - Norfolk & Western Railway |
