| Locator | NW Mech Dwg - NW-G16696 | Type | Drawing | Doc Number | G16696 | |
|---|---|---|---|---|---|---|
| Description | Trolley Sectionalization Plan Elkhorn Grade Electrification | |||||
| Notes | Scale 1"=1000' | |||||
| Date | 12/31/1915 | Revision Date | 01/25/1923 | |||
| Author | N&W Rwy - Motive Power | Accession | 2001.001 : Mark Faville | |||
|
|
|
Size: 36in x 62in (91cm x 157cm) |
| Related | G16696 | NW Mech Dwg - NW-G16696 | Trolley Sectionalizational Plan, Elkhorn Grade Bluefield Electrification Scale 1"=1000'. Traced from Gibbs & Hill Card No O-9562. "G-16696 Revised 1-25-23". Appears drawing was redrawn to 1/25/23 version. |
| Structure | Signals |
| Structure | Track - Diagram |
| Structure | Electrification |
